FISCHER 18093 - Assembly: Mounting Bike on Rack

13
GB
Placeyourbikeontheprofiledwheelguide
(partsno.2)asdepictedinIll.5,loosenthe
clamping knob on the side of the tube support
and then turn counterclockwise to the smallest
openingnecessarytoinsertthebikeframe.
SeeIll.4.
Now lift the opened frame support until it can
be attached to the bike frame. Now turn the
clamping knob clockwise until the fastening
elements on the frame support grasp the bike
frame.LocktheknobasdepictedinIll.6.
Then secure the bike wheels using the included
safetybelts(partsno.10),oneonthefront
wheelandtwoonthebackwheel.SeeIll.5.
Carefullymakesurethatthebikeissecurely
lockedinplace.Verifythatallpartsare
securelyfastenedandthattherubber
fastening parts on the frame support are not
deformed.Ifyouarecertainthatyourbikeis
securelyfastenedinplace,opentheclamping
knob and repeat the step, this time move the
protective parts on the frame support closer
totheframeofyourvehicle.
Lockusingthekeyandremovefromthebike
rack.Itisprohibitedtodrivewiththekey
insertedinthebikeracklock.Keepthekey
at a safe location.
Step 4
Mounting your bike on the bike rack Two persons are required to complete
this step correctly.
Ill. 4
Ill. 5
Ill. 6
