6.5 To remove the ignition switch loom
1. Remove the hob top and tray.
2. Lift the loom switches off the gas valves and unplug from the ignition box.
6.6 To remove the transformer
1. Remove the hob top and tray.
2. Remove the LED bracket by pulling it upwards and unplug the LED harness from the ignition
box.
3. Fold back the lugs holding the transformer to the basepan.
4. Disconnect the wiring from the transformer to the terminal block and ignition box.
Note: The black supply wires are not polarity dependent.
6.7 To remove a gas valve
1. Remove the cooktop from the benchtop.
2. Remove the hob top and tray.
3. Remove the ignition switch loom.
4. Remove the LED bracket by pulling it upwards and unplug the LED harness from the ignition
box.
5. Disconnect all the aluminium tubes from the gas valve outlets.
6. Remove the screws securing :
the manifold bracket to the base pan.
the solenoid block to the basepan.
the manifold support bracket to the basepan.
7. Remove the wires from the solenoid.
8. Remove the manifold.
9. Remove the gas valve from the manifold.
Note: Leak test all gas connections. Block each injector orifice in turn and open the valve to
leak test the gas connections beyond the valve.
Check and adjust the low flame setting.
