Fisher & Paykel DD24DC Installation Instructions

PLUMBING AND DRAINAGE OPTIONS
11
29 ½” - 34 ¾”
(750 -
882.5 mm)
1 ½”
(38 mm)
1
max. 4 ¾”
(120 mm)
2
1
6
5
4
7
2
29 ½” - 34 ¾”
(750 -
882.5 mm)
1
3
6
5
4
5
6
5
4
5
A
If space is limited for fixing, push
hose through drain hose support
to required height
DishDrawer® with Waste Disposal
29 ½ ” - 34 ¾ ”
(
750 - 882.5 mm)
min. R 8 ”
( 200 mm)
Supplied drain hose joiner
(ø
¾
” (19 mm)) waste tee)
HIGHLOOP
min. 6”
(150 mm)
DishDrawer® using Air Break
with Drain Hose Joiner
Supplied drain hose joiner
(
ø
¾
” (19 mm)) waste tee)
Air Break
37 ⁄” ( 950 mm)
Max. height to
top of Air Break
(countertop or
wall mounted)
Fit supplied
washer
Ensure hoses are routed
straight to joiner. Remove
excess hose material if
necessary.
DishDrawer® and Standpipe
Ø 1 1/2” (38 mm)
29 ½ ” - 34 ¾ ”
(
750 - 882.5 mm)
min. R 8 ”
( 200 mm)
Waste Disposal
(optional)
B
Fit supplied
washer
180
o
180
o
180
o
Ensure hoses are routed
straight to joiner. Remove
excess hose material if
necessary.
Fit supplied
washer
C
If space is limited for fixing, push
hose through drain hose support
to required height
