Fisher & Paykel DD603(I) - Dimensions and Specifications

D
D
i
i
m
m
e
e
n
n
s
s
i
i
o
o
n
n
s
s
a
a
n
n
d
d
S
S
p
p
e
e
c
c
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
Product Size
(mm)
Product Size
(inches)
Minimum
Cavity Size
Minimum
Cavity Size
Height (double) 817.5-867.5mm 32
3
/
16
inch 820-870mm 32
5
/
16
inch
Height (single) 407mm 16 inch 410mm 16
1
/
8
inch
Width 595mm 23
7
/
16
inch 600mm 23
5
/
8
inch
Depth 570mm 22
7
/
16
inch 580mm 22
7
/
8
inch
Drawer Open (incl cab) 1080mm 42 ½ inch
Electrical 230-240V AC 50Hz 10amp max. NZ/UK/AUS
110-120V AC 60Hz 12.5amp max USA.
SPECIFICATIONS
Water Inlet Valves
P/N525113 Dual
P/N525842 Single
Chassis PCB
P/N 525958
P/N 525959
Motor
Drain
Wash
Stator
P/N 526530
24Volt dc
70 ± 5 Ohms
5 l/min
(1.3 US gal/min)
240Volt AC
120Volt AC
80 Volt DC 3 Phase
4200rpm
2300-2850rpm
8.0 ± 1 Ohm
per winding
Detergent
Dispenser
P/N526536
Rinse Aid
Dispenser
Standby Power
DD603
DS603
24 volt dc
70 ± 5 Ohms
10 grams /2tsp
20 grams /4tsp
30 grams /6tsp
5 gram pre-rinse
10 gram pre-rinse
24 Volt DC
70 ± 5 Ohms
50 ml / 1.7fl oz
25 reg. Washes
approx
3w(NZ) / 2w(USA)
1.5w(NZ)/1w(USA)
Temperature Sensor
(Part of Heater
Plate)
Inlet Hose
P/N 521349
P/N 525970 USA
Drain Hose
P/N 525966
P/N 525967
962-Ohms @ 20°C (68°F)
1000-Ohms@ 30°C (86°F)
1202-Ohms @ 60°C (140°F)
1.7m (66 inches)
960Kpa / 139p.s.i.
2.0m (78 inches) from rear of
cabinet
2.5m (98 inches) bottom tub
2.9m (114 inches) top tub
Heater Plate
P/N 526443
Heater Track
Dropper
Resistor
P/N 526444
Heater Track
Dropper
Resistor
240 Volt ac
60Ω ± 5%
130Ω ± 5%
120 Volt ac
30Ω ± 5%
30Ω ± 5%
