4
Installation instructions
Before you start
Carefully read through the ‘Safety and warnings’ section of this document.
Check the packaging and the dishwasher for signs of transport damage. If there is any damage,
do not install the dishwasher but contact your Fisher & Paykel Authorised Service Centre or
dealer.
The dishwasher must not be connected to the power supply during installation.
Never lift the dishwasher from the door handle or the top panel.
Always be careful with the hoses and the power supply cable at the back of the dishwasher.
Careful handling will prevent malfunction from squashing, kinking or cuts.
The dishwasher should not be connected to a hot water system. The incoming water
temperature should not exceed 25 ºC.
The dishwasher must not be connected to an undersink high-pressure “push-through”-type hot
water system, as damage to the system will result.
Underbench or built-in appliances should be installed under a continuous surface which is
attached to adjacent cupboards, in order to ensure that the appliance is stable.
Technical data
Maximum Capacity 14 standard place settings
Mains water pressure 0.3 –10 bar
(= 3 – 100 N/cm = 0.01-1.0Mpa)
Power voltage 220-240 V – 50 Hz
Maximum current intensity 10 A
Power output 2000 W
Product and cavity dimensions (in mm)
* With top panel in place
** With top panel removed
0-50
*
*
*
0-50
Underbench installation
Freestanding installation
