9
!1SECURE THE OVEN TO THE CABINETRY
!2REFIT THE DOOR
IMPORTANT!

Do not lift the oven by the door handle.

Do not over-tighten the screws.

Do not seal the oven into the cabinetry with silicone or glue. This makes future
servicing difficult. Fisher & Paykel will not cover the cost of removing the oven, or
damage caused by this removal.
1 Position the oven in the prepared cavity.
2 Open the oven door fully.
3 Secure oven to cabinetry using supplied screws.
2.5 mm
1 Holding the door on both sides, line up
the holes in the base of the door with
the hinges and slide the door on.
2 Locking the door onto the hinges (hinges may vary):

OB60 models – Once the door is placed on the hinges, push each
locking lever up fully to lock the door onto the hinge.

OB60SD models – Ensure the door is firmly in place on the hinges.
Open the door completely again and push each locking lever down
fully to lock the door onto the hinge.
3 IMPORTANT!
Ensure the levers are both fully locked before trying
to shut the door.
OB60 models OB60SD models OB60 models OB60SD models
