REMOVING THE OVEN DOOR
The oven door can easily be removed as follows:
– Open the door to the full extent (fig. 6.12a).
– Open the lever “A” completely on the left and right hinges (fig. 6.12b).
– Hold the door as shown in fig. 6.12.
– Gently close the door (fig. 6.12) until left and right hinge levers “A” are hooked to part
“B” of the door (fig. 6.12b)
– Withdraw the hinge hooks from their location following arrow “C” (fig. 6.12d).
– Rest the door on a soft surface.
– To replace the door, repeat the above steps in reverse order.
Fig. 6.12
Fig. 6.12a
B
A
Fig. 6.12b
C
Fig. 6.12d
Fig. 6.12c
f
6
