8
GAS BURNERS
1. Rear left Semi-rapid burner (SR) - 8000 BTU/hr
2. Rear right Semi-rapid burner (SR) - 8000 BTU/hr
3. Front right Triple-ring burner (TR) - 12000 BTU/hr
4. Front left Triple-ring (TR) - 12000 BTU/hr
5. Central Dual burner (D) - 18000 BTU/hr
Note:
• The electric gas-lighting device is incorporated into the dials.
• The appliance has a safety valve system fi tted.
The fl ow of gas will stop if and when the fl ame should acciden-
tally go out.
Fig. 1.1
features
1
CAUTION:
If the burner is accidentally extinguished, turn the gas
off at the control dial and wait at least 1 minute before
attempting to relight.
CAUTION:
Gas appliances produce heat and humidity in the en-
vironment in which they are installed.
Ensure that the cooking area is well ventilated fol-
lowing national/local codes.
1
4
5
2
3
