Instruction Manual
D100325X012
1061 H & J Actuator
January 2016
19
source to move the actuator slightly off the up travel stop. If hole alignment cannot be obtained in this manner,
temporarily loosen the cap screws (key 24), and shift the housing slightly. Do not stroke the actuator while the
cover is off. Then, tighten both sets of cap screws to the torque values listed in table 7.
b. If a manual handwheel actuator is used, refer to the separate instruction manual for mounting instructions.
10. Follow the instructions in the Adjustment section for turnbuckle adjustment.
Parts Ordering
When corresponding with your Emerson Process Management sales office about this equipment, refer to the serial
number found on the actuator nameplate (key 42, figure 6).
WARNING
Use only genuine Fisher replacement parts. Components that are not supplied by Emerson Process Management should
not, under any circumstances, be used in any Fisher valve, because they may void your warranty, might adversely affect the
performance of the valve, and could cause personal injury and property damage.
Repair Kits
Key Description Part Number
Kits include keys 5, 8, 16, 17, 18, and 56.
Size 30 R1061X00302
Size 40 R1061X00402
Size 60 R1061X00602
Size 68 R1061X00682
Parts List
Note
Contact your Emerson Process Management sales office
for Part
Ordering information.
Key Description
Actuator
1 Cylinder Assembly, aluminum/stainless steel
2 Cylinder Flange, aluminum
3 Cap Screw, pl steel
4 Cylinder Cap, aluminum (for sizes 30, 40, & 68 only)
5*
(1)
O‐Ring, nitrile (for sizes 30, 40, & 68 only)
Key Description
6 Cap Screw, pl steel (2 req'd) (for sizes 30, 40, & 68 only)
7 Piston, aluminum
8*
(1)
O‐Ring, nitrile
9 Cap Screw, pl steel
9 Hex Nut, pl steel
Size 68 only
10 Piston Rod, pl S41600 (416 SST), heat treated
11 Hex Nut, pl steel
12 Rod End Bearing, pl steel/stainless steel
13 Cap Screw, pl steel
14 Hex Nut, pl steel
15 Travel Stop, steel (for 60‐degree rotation only)
16*
(1)
O‐Ring, nitrile
17*
(1)
O‐Ring, nitrile
18*
(1)
O‐Ring, nitrile
19 Sliding Seal, alum/PTFE anodize
20 Seal Support Cylinder, aluminum
21 Housing, cast iron
22 Cap Screw, pl steel
23 Mounting Plate, steel
23 Mounting Yoke, cast iron
24 Cap Screw, pl steel (4 req'd)
28 Lever, ductile iron
29 Cap Screw, pl steel
30 Hub, S41600 (416 SST) (not req'd w/handwheel)
31 Retaining Ring, pl steel (not req'd w/handwheel)
32* Bearing, fiberglass
34 Cover
35 Cap Screw, pl steel W/o handwheel
*Recommended spare parts
1. Included in repair kit.
