Fisher 249 - Parts Information; Parts Kits; Parts List; Sensor Common Parts

Instruction Manual
D200099X012
249 Caged Sensors
April 2017
13
not shown) attached to the torque tube arm. This same number also appears on the controller/transmitter nameplate
when a complete controller/ transmitter‐sensor unit is shipped from the factory.
WARNING
Use only genuine Fisher replacement parts. Components that are not supplied by Emerson Automation Solutions should
not, under any circumstances, be used in any Fisher instrument. Use of components not supplied by Emerson Automation
Solutions may void your warranty, might adversely affect the performance of the instrument, and could cause personal
injury or property damage.
Parts Kits
Description Part Number
Sensor Parts Kits
Kit contains keys 9, 11, 12, 13, 14
For 249
Kit includes 1 cage gasket (key 12) for
249 CL125 and 1 cage gasket (key 12)
for 249 CL250 R249X000022
For 249B R249BX00012
Parts List
Note
Contact your Emerson sales office
or Local Business Partner for Part
Ordering information.
Key Description
Sensor Common Parts
1 Cage
2 Cage Head
3 Torque Tube Arm
4 Driver Bearing
(1)
, S31600
5 Driver Bearing Bolt
(1)
, S31600 (2 req'd)
6 Retaining Flange (see above note)
Key Description
7 Rod/Driver Assy
(1)
, S31600 stainless steel (SST)
249 and 249B
249C
Standard wall torque tube
Heavy wall torque tube
249K
249L
8 Positioning Plate, Steel
9* Torque Tube Assy
(1)
249 and 249B
N05500
Standard wall
Thin wall
Heavywall
249C
S31600
Standard wall
Heavy wall
249K and 249L
N05500
Standard wall
Thin wall
10* Displacer
(1)
249 and 249B
3 X 14 Inches (1600 psi), S30400
2 X 32 Inches (1500 psi), S31600
1‐5/8 X 48 Inches (1800 psi), S30400
1‐1/2 X 60 Inches (1800 psi), S30400
1‐3/8 X 72 Inches (1400 psi), S30400
249C
1‐1/2 X 32 Inches (1300 psi), S31600
2‐3/8 X 14 Inches (1400 psi), S31600
249K
1‐3/4 X 32 Inches (4200 psi), S30400
2‐3/4 X 14 Inches (6000 psi), S30400
249L
2‐3/4 X 14 Inches (6000 psi), S30400
11* Cotter Spring
(1)
, N04400 (2 req'd)
12* Cage Gasket
(1)
For 249, Graphite‐stainless steel
(Unless otherwise noted)
CL125
CL250
249B 0Y0873X0082
249C 1F8305X0062
249K, composition‐stainless steel
*Recommended spare parts
1. This part is available in a wide variety of materials of construction, part dimensions, or other
specifications. Listed here are standard or typical materials, dimensions, or specifications.
Contact your Emerson sales office for assistance in selection of specific materials, dimensions,
or specifications.
