Fisher FSAIF-CP-91AE3 - Electrical Characteristics

Specifications
 Page 25 
8. Electrical Characteristics
Model
Indoor Unit Power Supply IFM
Phase Hz Voltage MCA MOP kW FLA
FSAIF-CP-91AE3
1 50
220-240
min:198
max:264
-- -- 0.02 0.16
FSAIF-CP-121AE3
-- -- 0.02 0.16
FSAIF-CP-181AE
-- -- 0.03 0.11
FSAIF-CP-241AE3
-- -- 0.058 0.206
Model
Outdoor Unit Power Supply Compressor OFM
Phase Hz Voltage MCA MOP MSC RLA Qty kW FLA
FSOAIF-CP-91AE3
1 50
220-240
min:198
max:264
7.52 12.82 / 5.3 1 0.034 0.89
FSOAIF-CP-121AE3
7.52 12.82 / 5.3 1 0.034 0.89
FSOAIF-CP-181AE3
9.76 16.91 / 7.15 1 0.08 0.82
FSOAIF-CP-241AE3
12.45 21.75 / 9.30 1 0.08 0.82
Notes:
MCA: Minimum Circuit Amperes (A)
MOP: Maximum rating over current protective device
MSC: Maximum Starting Current
RLA: Rated Load Amperes (A)
IFM: Indoor Fan Motor
OFM: Outdoor Fan Motor
FLA: Full Load Amperes (A)
