Specifications
Page 8
Outdoor coil
Number of rows 1.6 2
Tube pitch(a)x row pitch(b) mm 21x22 21x13.37
Fin spacing mm 1.3 1.3
Fin type (code) Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia.and type mm Ф7,Inner groove tube Ф7,Inner groove tube
Coil length x height x width mm 900*44*609 900*44*609
Number of circuits 5 6
Outdoor air flow m3/h 3500 3500
Outdoor sound pressure level dB(A) 56 59
Outdoor sound power level dB(A) 65 68
Outdoor unit
Dimension(W*D*H) mm 890x342x673 890x342x673
Packing (W*D*H) mm 995x398x740 995x398x740
Net/Gross weight Kg 38.8/41.9 45.6/48.8
Refrigerant
Type R32 R32
GWP 675 675
Charged quantity Kg 1.1 1.5
Design pressure MPa 4.3/1.7 4.3/1.7
Refrigerant piping
Liquid side/ Gas side mm(inch) Φ6.35/Φ12.7(1/4"/1/2") Φ9.52/Φ15.9(3/8"/5/8")
Max. refrigerant pipe length m 30 50
Max. difference in level m 20 25
Connection wiring 1.5x5Core 2.5x5Core
Plug type no-plug no-plug
Thermostat type Remote Control Remote Control
Operation temperature 16-30 16-30
Ambient tem-
perature
Indoor(cooling/ heating) °C 16-32/0-30 16-32/0-30
Outdoor(cooling/heating) °C -15-50/-20-24 -15-50/-20-24
Qty’per 20’ /40’ /40’HQ 65/137/156 56/120/134
Notes:
1) Capacities are based on the following conditions:
Cooling(T1): - Indoor Temperature 27°C(80.6°F) DB /19 °C(66.2°F) WB Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
-Outdoor Temperature 35 °C(95°F) DB /24 °C(75.2°F) WB -Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
-Interconnecting Piping Length 5m - Interconnecting Piping Length 5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are Net Capacities.
3) Due to our policy of innovation some specifications may be changed without notification.
