Fishman BP-100 User Manual

3. Weave the ground wire over the string ball-ends making sure to contact
each ball.
4. Determine which isolation plug fits snugly into the E-string side wing-hole
on the bridge. Slip the wire
into the slit of the isolation
plug and fit the plug into the
wing-hole.
FINE TUNING
• Mounting the elements 1/4" to
1/2" below the top edge of the
bridge will produce a different
sound.
• You may fine tune the string
balance by moving the upper
corner of an element closer to
or further from an individual
string.
• Once the optimum position is
determined, the elements
should not be disturbed or
removed from the instrument.
• The mounting clips must be
tight. They should be retight-
ened after installation to com-
pensate for compression of
the felt.
4
4
BP-100 Acoustic Bass Pic
BP-100 Acoustic Bass Pic
kup
kup
