Electrical Specifications
Power consumption: 15mA
Typical 9V lithium battery life: 66 hours
Typical 9V alkaline battery life: 33 hours
Maximum output level (onset of clipping): +1dBV
Nominal output impedance: 1k Ohm
Input trim gain range: -6dB to +6dB
Peak meter response: 3dB before clipping
Voicing switch, bass boost: +3dB @ 90Hz
Dynamic range: 93dB
Baseline noise: -92dBV
Anti-feedback cut depth: 13.5dB
Anti-feedback bandwidth: 0.25 octave
Phase switch, out position: (+) non-inverting output
The specifications in this manual are subject to change without notice.
