Fishman F1 Aura - Electrical Specifications; Signal Path and Power Specifications; Output, Noise, and Control Specifications

19
Electrical Specifi cations
Digital Signal Path:
A/D, D/A conversion: 24-bit
Signal Processing: 32-bit
Typical in-use current consumption @ 9VDC: 18mA
Typical 9V lithium battery life: 54 hours
Typical 9V alkaline battery life: 27 hours
Nominal output impedance: 1k Ohm
Recommended load impedance: 10k Ohm and up
Maximum output level (onset of clipping): +5dBV
Baseline noise: -92dBV
Dynamic Range: 97dB
Bass control: ±12dB @ 70Hz
Midrange control: ±12dB @ 1kHz
Treble control: ±12dB @ 6.5kHz
All specifi cations subject to change without notice.
