10
Rear Panel
1. DC In
Operate the amplifi er only at the voltage indicated on the rear panel.
Plug in the supplied DC cable into the DC In power socket on the amp. Plug the
provided AC cable with the female IEC-style 320 connector into the AC Adapter
and the male AC plug appropriate for your region into an outlet.
The DC In is the power input, and when connected appropriately as described
above, it will also simultaneously charge the battery if it is below full charge. The
amplifi er may be used while charging and may be charged when powered down.
See the battery indicators on the front panel for battery charge status.
2. Power switch
Lower the Master Volume before you turn on the amp. Flip the power switch to
the up position for On.
3. Aux Input - 1/8”
Plug in a line-level stereo audio source such as a CD or MP3 player in this input.
The input is stereo; however, the left and right signals are mixed to mono within
the amplifi er.
4. Mix D.I. (Post)
Plug in here when you wish to send signals from both Channel 1 and 2, plus 1/8”
Aux and Bluetooth signals, to a mixing console or a slave amplifi er. This post-EQ
output is always ground-isolated to prevent ground loop hum.
1 2 3 4
Aux Input
12V 5A
DC In
