Front Panel Controls
Boost
The boost foot switch creates an increase in volume only when the LED
above the foot switch is lit. The range of volume boost can be set from
3dB to 12dB using the boost level control found on the right side
panel.
Tuner
Platinum Pro EQ features an integrated digital tuner with selectable tun-
ing modes and reference tuning frequency adjustment. To activate the
tuner, press the tuner foot switch: the tuner LED will light and the audio
outputs will be muted.
Tune mode: ve tuning modes are available: fully-chromatic, ukulele,
bass, guitar, violin. When in these modes, the display will indicate string
number as well as degree of tune.
Tune ref.: pressing this button changes the reference tuning frequency
for situations that do not call for an A note reference of 440Hz.
Battery
The battery indicator will light steadily when it is time to change the
battery. Open the battery door underneath the pedal and install a fresh
9V alkaline or lithium battery. When the battery LED comes on you have
approximately one hour of remaining battery life.
