Specifi cations
Nominal Input Level: -20dBV
Input Overload Level: +6dBV
Input Impedance: 10MW
Nominal output levels and impedances
¼” Out: -23dBV + 3dBV (1kW )
Tuner/Send Out: -.23dBV + 3dBV(1kW )
XLR Out: -32dBV -6dBV (600W )
Bass Control Range: ±12dB at 60Hz
±3dB at 350Hz
Treble Control Range: ±12dB at 10kHz
±3dB at 2.4kHz
Mid Control Range: ±12dB (adjustable from
250Hz to 5kHz) Q=0.5
Brilliance Control Range: ±9dB at 10kHz
±3dB bandwidth 7kHz
