RIELLO BURNER F10 - PARTS LIST DIAGRAM
N#
PART NUMBER
DESCRIPTION
1
FV-20136636-OIL
PLASTIC BURNER COVER C/W LABELS
2
FVO-3006992
SUPPLY LINE
4
FVO-3006993
RETURN LINE
16
FVO-3020076
PUMP ADAPTER FOR NOZZLE HOLDER FUEL LINE
18
FVO-C700-1029
IGNITION MODULE
19
FVO-3002278
SUB-BASE FOR IGNITION MODULE
20
FVO-3006553
COIL U-BRACKET C/W KNURLED NUT
21
FVO-3002279
PUMP COIL
22
FVO-20136488
BURNER PUMP
23
FVO-3000443
PUMP DRIVE KEY
24
FVO-C7001034
BURNER MOTOR
25
FVO-3007317
AIR TUBE COVER PLATE
26
FVO-20132573
PHOTO CELL
27
FVO-3005854
SEMI FLANGE
28
FVO-3005855
MOUNTING FLANGE
30
FV-3005788
BURNER FAN
31
FVO-3005844
BURNER CAPACITOR
32
FVO-3007205
AIR DAMPER
33
FVO-3006978
TURBULATOR DISC
34
FVO-3006966
ELECTRODE SUPPORT
35
FVO-20136639
NOZZLE HOLDER
36
FVO-3005889
REGULATOR ASSEMBLY
37
FVO-3005891
ELECTRODE ASSEMBLY
38
FVO-3005869
ELECTRODE PORCELAIN
39
FVO-3006982
BLAST TUBE
40
FVO-3006983
END CONE ADAPTER
41
FVO-3006984
END CONE
42
FVO-20136491
PREHEATER
