Flavel Strata - Installation; Safety Warnings; Appliance Data

Supplied By www.heating spares.co Tel. 0161 620 6677
CONTENTS
Contents
Installation Instructions Page
Appliance Data 3
Section 1 1.1 Conditions of Installation. 4
1.2 Flue & Chimney Suitability 4
1.3 Fireplace/Surround Suitability 5
1.4 Shelf Position 5
1.5 Side Clearance 5
1.6 Closure Plate 5
1.7 Flue & Chimney inspection 5-6
1.8 Chimney Catchment space 6
1.8.1 Brick Built Chimney 6-7
1.8.2 Fitting to Pre-Fab. Twin Wall
Metal Flueboxes 7
1.8.3 Fitting to Pre-Cast Flue Installations 8
1.9 Hearth Fitting 8
1.10 Wall Mounting 8
1.11 Spillage Monitoring System 8
Section 2 2.1 Packing Check List 8
2.2 Installation of Fire 8-12
2.3 Gas Connection 12
2.4 Gas Soundness 13
.
Section 3 3.1 Completing the Assembly 13
3.2 Lighting the Appliance 13
3.3 Checking for Clearance of
Combustion Products 14
3.4 Final Checks 15
Section 4
Maintenance Instructions
4.1 General Access for Servicing 16
4.1.1 Removal of the Outer Case 16
4.2 Removal of the Burner Assembly 17
4.3 Removal of the Control Tap 18
4.4 Removal of the ODS 19
4.5 Removal / Replacement of the Radiants 19-20
2
