REPLACING THE RADIANTS
When replacing the radiants, always ensure that they are correctly located as
shown in Fig. 13 below.
Fig. 13
Due to our policy of continual improvement and development the exact
accuracy of illustrations and descriptions contained in this book cannot be
guaranteed.
PARTS SHORTLIST
Replacement of parts must be carried out by a competent person such as a
CORGI registered gas installer. The part numbers of the replaceable parts are as
follows, these are available from your local Flavel stockist, whose details can be
found on the CFM Europe website, address on the back page
Ceramic Radiant Plaques B-48680
Gas Valve with integral ignition & lead B-48350
Control knob B-48590
ODS Pilot Assy B-48360
Closure plate 1C-48740
20
Front edge of the Positioning Plate
Ensure that the rear face of
the ceramic radiant is touching
the front edge of the position-
ing plate as indicated
