engage,
then
check
for
a
blown
fuse,
loose
connec-
tions
or
damaged
or
deteriorated
wires.
If
these
checks
are
OK,
then
the
problem
may
be in
the
com·
pressor
clutch
or
switch.
Take
the
vehicle
to
a
qualified
shop
for
further
testing.
Electrical
Circuit
Diagnosis
The
blower
electrical
circuit
and
motor
is OK
if
the
blower
operates
at
all
of
the
designated
speeds.
If
the
blower
does
not
work
at
all,'
then
check
for
a
blown
fuse,
loose
connections,
and
for
damaged
or
deteriorated
wires.
If
these
checks
are OK
and/or
the
blower
does
not
operate
at
all speeds,
then
the
pro'
blem
may
be
in
the
switch,
relay
or
motor.
Take
the
vehicle
to
a
qualified
shop
for
further
testing.
Vacuum
System
Diagnosis
If.
the
air
is
.not
flowing
through
the
proper
outlets
(floors,
dash
...
or
defroster),
then
there
may
be a pro-
.
blem
in
the
vacuum system,
or
with
the'diverter doors.
,Take,
the
vehicle,
to.a·
qualified·
shOp
for
further·
testing.
Refrigeration
Section
WARNING:
BECAUSE
OF.
THE, NATURE OF
REFRIGERANT-12
AND
THE
HIGH
PRESSURES
WHICH
ARE PRESENT
IN
THE 'REFRIGERANT
SECTION OF
THE SYSTEM, PERSONAL INJURY
CAN RESULT IF PROPER DIAGNOSTIC,
AND
SERVICE'PROCEDURES ARE
NOT
FOLLOWED.
THEREFORE,
REFER
ALL'
SUCH
WORK RE-
QUIRED
ON
THE
SYSTEM'
TOA
QUALIFIED
SHOP
WITH
THE NECESSARY TRAINED PER-
SONNEL
AND
EQUIPMENT.
',~,
FRONT'SUSPENSION
AND
ALIGNMENT
The
term
"front
alignment"
refers
to
the
angular
relationships
between
the
front
wheels,
the
front
suspension
attaching
parts
and
the
ground.
Several
factors
can
affect
front
alignment, including
.. tire
inflation
pressures,
wheel
bearing condition, steer-
ing
and
suspension
components.
The·
following
cheCKS
can
indicate
problems
that
sh()uld be
corrected.
1.
Check
all
tires
for
proper
inflation
pressures
and
approximately
the
same
tread
wear.
2.
If
the
unit
is
equipped
with
air
suspension
com-
ponents,
be
sure
to
inspect,them
according
to
the
literature
included
in
the
Owner's
··Information
Package.
Be
sure
to
keep
them
inflated
to
the'
recommended
pressures.
3.
Check
for
a
difference
in
the
ride
height
between
right
and
left
sides
of
the
vehicle.
NOTE:
Excessive
or
unevenly
distributed
loads
also
affect
ride
height
and alignment. This should
be
taken
into
consideration
when
making
the
check.
Also,
if
the
motor
home
is
equipped
with
air
bag
cylinders,
it
is
important
that
the
cylinders
be
inflated
to
the
proper
pressure
for
the
load
42
being carried
in
order
to
maintain
adequate
ride
height.
.
Further diagnosis and
alignment
checks
can
b,
made
at
a
qualified
alignment/front
end
shop.
REAR SUSPENSION
(Mor-Ryde
equippec
vehicles
only)
NOTE:
U-bolts
must
be
re·torqued
at
the
first
500
miles
of
vehicle use.
Torque
Specifications:
5/8"
U-bolts
-
150
ft.
ltis.
3/4'
U-bolts
...;
225ft.
Ibs.
Your dealer service
department
can arrange
for
this
service.
,-
NOTE on vehicles
with
tag
axles: The
tag
axle
assembly is
not
part
of
either
your
Chevrolet, Ford
or
Oshkosh chassis, Refer .service and/or
warran-
'ty
repairs
to
your
Fleetwood
motor
home
dealer.
:--!
-.
- ;"ri, . >
,,,.,
.',
•••
_,
' ,
JACKING PROCEDURE (Mor-Ryde Tandem
Axle
equipped vehicles
only)
Place
the
jack
at
the
chassis
frame
or
on
the
ends
of
the
cross-shaft
where
the
rubber
springs
are
attached.
DO NOT PLACE THE
JACK
ON
THE
SUSPEN-
SION SYSTEM CENTER
CROSS-SHAFT
TUBE.
JACKING ON THE
CROSS-SHAFT
TUBE
WILL
BEND THE TUBE. .
BRAKES
On Chevrolet chassis,
the
master
cylinder
is
located
under
the
driver's
compartment
floor, and js
reached
through
the
left
front
wheel
well.
On Oshkosh and Ford chassis,
the
master
cylinder
is
located
near
the
left
front
of
the
transmission
bet-
ween
the chassis rails.
Fill the master
cylinder
with
a squeeze bulb
or
pump.
Check
and
fill
the
master
cylinder
according
to
in-
structi.ons
in
the
chassis
operator's
manual.
Brake Hose Inspection
'_.
Inspect
the
flexible hydraulic brake
hoses
which
transmit
hydraulic pressure
from
the
steel
brake
pipe
on
the
frame
to
the
brake
assemblies
at
the
wheels
,.regularly in
accordance
with
the
chassis
manufac-
turer's
Maintenance Schedule.
Check
for
road
hazard
damage, cracks and
chafing
of
the
outer
cover,
and
for leaks and blisters. A
light
and
mirror
may
be
need-
ed
for
an adequate inspection.
If
any
of
the
above
conditions
are observed on
any
brake hose, have
it
replaced.
Lining Inspection
(
Inspect
the
brake linings per
the
chassis
manufac-
turer's
Maintenance Schedule and
any
time
that
the
wheels
are
removed (tire
rotations,
etc.).
To Next Page
