JS 18.0-EC /
JSB 18.0-EC
16
Adjusting the Foot Bevel AngleAdjusting the Foot Bevel Angle
To adjust the cutting angle
Turn the tool upside down.
Move the foot slightly forward and tilt it to
the required angle (0° or 45° ) using the
scale (0° or 45° ) that is marked on the
base bracket.
The foot has indents at 0° and 45° (tilt left or
Installing and disassembling of Installing and disassembling of
accessoriesaccessories
CAUTION!CAUTION!
Use the cover plate when cutting decorative
veneers, plastics, etc. It protects sensitive or
delicate surfaces from damage. Fit it on the
back of the tool base
Cover plateCover plate
Installation:
First, the front part of the plate cover is
Then the rear cover of the cover is aligned
Disassembly:
Firstly, the two card positions on the
back of the plate cover are removed (see
Then the bottom plate is turned down.
After about 30° , the front card position
Adapting boardAdapting board
Installation:
Insert the adapting board from the front of
the foot about a distance along the slot (a
certain distance from the saw blade).
When using the adapting board for the
on, align the foot surface, push the
adapting board, and insert the adapting
board along the slot (see Figure M) while
the saw blade is sawed in the middle of
the adapting board.
A slit makes the adapting board and the
cutting quality (see Figure N).
When the adapting board is inserted,
there are two limit positions, which
service life.
Disassembly:
saw blade and pull out the adapting board
directly (see Figure O).
Transparent CoverTransparent Cover
Installation: Insert the transparent cover from
and remove the transparent cover forward.
Vacuum tubeVacuum tube
Installation:
Let the front of vacuum tube toward the
saw blade, insert the middle snap into the
Push the vacuum tube backward, and
align the front screw with the screw hole
on the foot, screw the vacuum tube (see
The vacuum tube can be mounted
on either side of the right or left to
of the foot.
Disassembly:
Loosen the screw and push the vacuum
tube slightly forward to remove it directly.
JS 18.0-EC:
Switching on: push the switch button
forwards and release.
forwards and release.
The left and right switch buttons function
are the same.
JSB 18.0-EC:
On: Lock button moves to the middle
so you can see it on the left and right.
in and the lock button pushed to the far
