JS 18.0-EC /
JSB 18.0-EC
17
LED LightLED Light
Your tool is equipped with an LED light, located
on the front of the tool. This provides additional
light on the surface of the workpiece for
operation in lower-light areas.
The LED light will automatically turn on with a
slight squeeze on the trigger switch before the
10 seconds after the trigger switch is released.
When the machine is equipped with a battery
long as the LED switch (1) is pressed.
The LED light has a Memory function with save
the last setting.
Speed adjusting dial Speed adjusting dial
The tool speed can be adjusted by turning the
speed adjusting dial. You can get the highest
speed at 5 and the lowest speed at 1.
Refer to the table to select the proper speed
for the work piece to be cut. However, the
thickness of the workpiece. In general, higher
speeds will allow you to cut workpieces faster
but the service life of the blade will be reduced.
When the speed adjusting dial is in the position
A, the tool automatically reduces the no-load
speed to reduce the vibration under no-load.
Once the tool gets load, the tool speed reaches
the highest value.
Workpiece to be cut Number on adjusting dial
Wood 4-A
Mild steel 3-A
Stainless steel 3-4
Aluminum 3-A
plastics 1-4
Orbital-Action SettingsOrbital-Action Settings
Your tool is equipped with four orbital-action
settings for optimal adaptation to the cutting
speed, cutting capacity, cutting pattern, and the
material being sawed.
The orbital action can be adjusted with the
control lever:
The optimal orbital action setting for the
respective application can be determined
through practical testing. The following
recommendations apply:
Position Cutting action Applications
0
Straight line
cutting action
For cutting mild steel,
stainless steel and
plastics. For clean
cuts in wood and
plywood
1
Small orbital
action
For cutting mild steel,
aluminum and hard
wood
2
Medium
orbital action
For cutting wood and
plywood. For fast
cutting in aluminum
and mild steel.
3
orbital action
For fast cutting in
wood and plywood
NOTICE:NOTICE:
determine the best setting.
In order to reach full orbital action, the blade
must be facing straight forward, the back of
the blade must be resting in the groove of the
roller, and the foot must be positioned all the
way forward. Orbital action is not detectable
when the saw is running freely. The saw must
be cutting in order for orbital action to occur.
The cutting speed is easier to see when cutting
thicker material.
Cutting TipsCutting Tips
WARNING! WARNING!
Before attaching the battery pack onto the
tool, always check to determine that the
switch performs properly and returns to the
“OFF”position when released.
WARNING! WARNING!
Always wear safety goggles or safety glasses
with side shields during power tool operation or
when blowing dust. If operation is dusty, also
wear a dust mask.
WARNING!WARNING!
To avoid loss of control and serious injury,
make sure that the blade reaches the full
desired speed before touching it to the
workpiece.
Face the good side of the material down and
secure it in a bench vise, or clamp it down. Draw
cutting lines or designs on the side of the material
facing towards you. Place the front edge of the
saw foot on the workpiece and align the blade
To Next Page
