JS 18.0-EC /
JSB 18.0-EC
15
Identify additional safety measures to protect the
maintain the tool and the accessories, keep the
hands warm, organisation of work patterns.
CAUTION! CAUTION!
Wear ear protection at a sound pressure above
85 dB(A).
Battery information:
Battery
AP18.0
(2.5Ah)
AP18.0
(5.0Ah)
Weight of
battery/kg
0.42 0.72
Average battery
life (depending
on speed, tool
diameter, load ...)
/min
5 10
Overview Overview
The numbering of the product features refers to the
illustration of the machine on the graphics page.
1 LED Light switch1 LED Light switch
2a Lock button2a Lock button
3 Rating plate3 Rating plate
4 Speed control dial4 Speed control dial
5 State of charge indicator5 State of charge indicator
6 Release button for battery6 Release button for battery
7 Li-ion battery (2.5 Ah or 5.0 Ah)7 Li-ion battery (2.5 Ah or 5.0 Ah)
8 LED light8 LED light
9 Tool-less blade change handle 9 Tool-less blade change handle
10 Oribit-control level10 Oribit-control level
11 Foot11 Foot
12 Vacuum tube 12 Vacuum tube
Operating instructionsOperating instructions
NOTE NOTE
For further information on the manufacturer’s
products go to
WARNING! WARNING!
Remove the battery before carrying out any
work on the power tool.
Before switching on the power toolBefore switching on the power tool
Unpack the jigsaw and check that there are no
missing or damaged parts.
NOTE NOTE
The batteries are not fully charged on delivery.
Prior to initial operation, charge the batteries
fully. Refer to the charger operating manual.
Inserting/replacing the batteryInserting/replacing the battery
Press the charged battery 7 into the power
To remove, press the release button and
CAUTION! CAUTION!
When the device is not in use, protect the
battery contacts. Loose metal parts may short-
Installing and Removing the Saw Installing and Removing the Saw
BladeBlade
WARNING! WARNING!
pack before making any adjustments or
assembling parts.
To install the saw blade:
Insert the blade (with its teeth facing the cutting
direction) into the slot of the tool-less blade
Pull down on the blade to verify that the blade
is securely locked in place.
NOTICE:NOTICE:
When inserting the saw blade, the back of
the blade must rest in the groove of the guide
roller.
NOTICE:NOTICE:
The tool accepts most commonly available
T-shank blades.
To remove the saw blade:
Rotating the tool-less blade handle and remove
Release the tool-less blade handle.
WARNING! WARNING!
Use always protective gloves when removing
the saw blade from the tool. The saw blade is
sharp and may be hot after prolonged use.
