Installation
1) Mount the arm in the pivot of the angle mount.
2) Adjust the counterbalance of the arm to eliminate the possibility of the arm striking the
operator when positioned at its lowest point.
3) Connect the machine to a grounded 110 volt, 1 phase electric supply.
CAUTION: When making repairs to this unit, always disconnect the main power supply.
4) Flip the forward switch on the hydraulic motor of the tapping head. The rotation of the
hydraulic motor is correct if the tapping head rotates clockwise. If it turns
counterclockwise or does not rotate, reserve the two phases at the supply connection,
not in the internal electric panel.
5) Always wear safety glasses and use proper safety precautions when operating this unit.
Gloves are not recommended when operating this machine.
ALWAYS SECURE THE WORK PIECE TO THE TABLE BEFORE OPERATING.
This machine is designed for tapping, chamfering and light reaming of holes up to M18 diameter.
FlexArm Inc is not responsible for accident or injury resulting from the misuse of this machine.
GH-18 Startup and Shutdown Procedures
Startup:
1. Plug in
2. Lockout breaker on
3. Green button press on (Hold for 2-3 seconds on initial startup)
Shutdown:
1. Red button off
2. Lockout breaker off
a. allow the motor in the power pack to spool down completely before turning lockout breaker
off (approximately 3 seconds)
b. this is only necessary if locking out the unit
3. Unplug (this is only necessary if moving locations)
a. allow the motor in the power pack to spool down completely before unplugging the unit
(approximately 3 seconds)
