Enter in device 2 with the Monitor (LCT, RS-232 or USB) or Telnet interface.
Go to Configuration Management (CM)
Set everything to default configuration
Configure SHDSL 1 as SLAVE
Configure SHDSL 2 as SLAVE
Configure Ethernet over SHDSL 1
Configure Ethernet over SHDSL 2
Set the IP-address of the device
Go to Configuration Management (CM)
Go to Fault and maintenance management (FMM)
Apply all configurations (written in the running config.)
Confirm all configurations (written in the startup config.)
In Menu Configuration Management (CM) you can type <CONFIG> to see the following picture:
CP_CM>CONFIG
--------------------------------------------------------------------------------
Running Line Configuration
--------------------------------------------------------------------------------
xDSL DSL1 DSL2
Mode : Slave(HTU-R) Slave(HTU-R)
Extended rates: OFF OFF
Line coding : PAM32 PAM32
Baserate : 89 89
Annex : B B
Payload : WAN WAN
Clock source : Int Int
GS compatible : OFF
NM threshold : OFF
LA threshold : OFF
--------------------------------------------------------------------------------
CP_CM>
The idea is the following: the default settings help any device to be in an initial state, then the MASTER/SLAVE mode is
enabled on the modem, then the transmit data is configured, then the network settings are configured (IP address, default
subnet mask and default gateway) and finally, these settings are applied and then are written in the EEPROM.
ATTENTION
DON’T FORGET TO WRITE THE CONFIGURATION IN THE STARTUP CONFIGURATION WITH
THE FOLLOWING COMMANDS:
Go to Fault and maintenance management (FMM)
Apply all configurations (written in the running config.)
Confirm all configurations (written in the startup config.)
