FlexDSL Telecommunications AG
Steinackerstrassse 31
8902 Urdorf
Switzerland
Page 4/9
Tel: +41 44 741 52 90
Fax: +41 44 741 52 93
Email: info@flexdsl.ch
Web: www.flexdsl.ch
Connector Description
SHDSL Technical Specification
SHDSL Connector Specification
Specification
ITU-T G.991.2 G.shdsl and G.shdsl.bis
Pin No
Description
Line Code
TC-PAM16/32, Extended: TC-PAM4/8/64/128
1
NC (not used)
Impedance
135
2
NC (not used)
Transmit Power
13.5 (Annex A) or 14.5 (Annex B) dBm @ 135
3
SHDSL interface B *
Number of Pairs
2 or 4
4
SHDSL interface A
Bit Rate
192 to 5704kbit/s, Extended: 128 to 15232kbit/s
5
SHDSL interface A
Overvoltage Protection
ITU-T Rec. K.20/K.21
6
SHDSL interface B *
Connector Type
RJ-45 Female, 8 pin
7
NC (not used)
8
NC (not used)
* only used in V84
Specification
ITU-T G.991.2 G.shdsl and G.shdsl.bis
1
SHDSL interface B (2)
Line Code
TC-PAM16/32, Extended: TC-PAM4/8/64/128
2
SHDSL interface B (2)
Impedance
135
3
SHDSL interface D (4)
Transmit Power
13.5 (Annex A) or 14.5 (Annex B) dBm @ 135
4
SHDSL interface D (4)
Number of Pairs
4
5
SHDSL interface A (1)
Bit Rate
192 to 5704kbit/s, Extended: 128 to 15232kbit/s
6
SHDSL interface A (1)
Overvoltage Protection
ITU-T Rec. K.20/K.21
7
SHDSL interface C (2)
Connector Type
Phoenix Mini Combicom MCD 1,5/4-G1F-3,81
8
SHDSL interface C (2)
Female, 8 pin
only used in V84I, V84IS
Matching Type for Cable
FK-MCP 1,5/ 4-STF-3,81
For AWG 16-28
Area 0.141.5 mm
2
or Diameter 0.42-1.4 mm
Ethernet Technical Specification
Ethernet Connector Specification
Standard:
IEEE-802.3, VLAN/QoS IEEE-802.1q/p
Pin No
Description
Number of Interfaces
2/4
1
Tx+ (transmit data)
Data Rate
10/100BaseT, Full/Half Duplex
2
Tx- (transmit data)
Protocols
Data, Telnet, SNMP, WEB
3
Rx+ (receive data)
Signal Level
Ethernet
4
NC (not used)
MDI/MDI-X auto crossover
Supported
5
NC (not used)
Auto Negotiation
Supported
6
Rx- (receive data)
Connector Type
RJ45 Female, 8 pin,
7
NC (not used)
8
NC (not used)
100Base-FX Ethernet (V84S, V84IS)
SFP Connector
Standard:
IEEE-802.3, VLAN/QoS IEEE-802.1q/p
Data Rate
100BaseT, Full/Half Duplex
Signal Level
Ethernet
Connector Type
Type SFP Tyco 1658391-1, only V84S
Type SFP Amphenol UE78-B1126 only V84IS
Recommended 155Mbps SFP Transceiver (Fast Ethernet, OC-3, STM-1):
LS38-A3S-TC-N
XGSF-03-1503-80
E1 (G.703) Technical Specification
E1 (G.703) Connector Specification
Specification
ETS 300 166, ITU-T Rec. G.703, G.704
Pin No
Description
Number of Interfaces
2
1
E1 Input → CH1/2 Wire A
Line Code
HDB3
2
E1 Input → CH1/2 Wire B
Impedance
either 120 or 75
3
NC (not used)
Jitter
ITU-T Rec. G.823, ETSI TS 101 135
4
E1 Output → CH1/2 Wire A
Bit Rate
2048kbit/s ± 50 ppm
5
E1 Output → CH1/2 Wire B
ESD Protection
8kV (Air discharge)
6
NC (not used)
Connector Type
RJ45 Female, 8 pin
7
NC (not used)
8
NC (not used)
