3. Install the ceiling brackets using tapping screws (6) and tighten with socket wrench.
Step 2-A: Install Ceiling Brackets Parallelly
¢
Wooden Ceiling Joists
Note: The installation template is
reusable for marking mounting
points on each side.
Mark the Mounting Holes
Power Drill
2.4'' (60mm)
0.18'' (4.5mm)
1. Use a stud finder to locate the wooden ceiling joists. Then use the installation template
to mark the mounting points.
2. Drill a 2.4'' (60mm) deep 0.18'' (4.5mm) diameter pilot hole at the center of each marked
point.
05 06
6
Ceiling Brackets
Wooden Ceiling Joists
To Next Page
