Fleximounts GR48FB - Step 5: Assemble Frames; Step 6: Place and Attach Frames

11 12
Step 5: Assemble the frames
Frame Bars
1. Assemble the 8 bars into 2 frames.
2. Assemble the frame reinforcement bar. 3. Flip over the frame and attach
the reinforcement bar.
Step 6: Place and attach the frames to vertical posts
Note:
To avoid misalignment of holes when installing screws,
do not tighten any screws until all screws are loosely
installed. Then tighten the screws one by one.
