13 14
1
2
Use of Metal Expansion Bolt
The metal expansion bolt is needed if installing to a concrete ceiling (metal expansion bolts are
not included).
Tap the metal expansion bolt into
the mounting hole.
Screw out the nut and washer.
3
4
Install the ceiling bracket.
Tighten the nut with a socket wrench.
Installation Tips
Step 7: Assemble the plywood
Place the board on the frame,select the appropriate self-tapping screws.
Lock the board and frame from bottom to up.
Note:
Recommended plywood size:
2 sheets of 4'x 4' plywood.
Recommended plywood thickness:
3/8" plywood or thicker.
Note:
Fleximounts give ST4.2 x 10 Tapping Screws 16.
If not suitable,you need to buy screws according
to the thickness of the board.
16
