07 08
Step 2-B: Install Ceiling Brackets Perpendicularly
¢
2.4'' (60mm)
0.18'' (4.5mm)
Wooden Ceiling Joists
48"
48"
48"
Note: The installation template is
reusable for marking mounting
points on each side.
Mark the
mounting holes
Power Drill
1. Use a stud finder to locate the wooden ceiling joists. Then use the installation template
to mark the mounting points.
2. Drill a 2.4'' (60mm) deep 0.18'' (4.5mm) diameter pilot hole at the center of each marked
point.
Ceiling Brackets
Wooden ceiling joists
6
3. Install the ceiling brackets using tapping screws (6) and tighten with socket wrench.
To Next Page
