NB! Turn the edges of the dust bag down into
the container. This is to avoid damaging the
bag with the lid
4.2 Replacing / cleaning of filter
Open the lid and take out the dust bag as described earlier.
The filter sits at the bottom of the container around the
motor housing.
Pull the filter out of the container, Fig. 12. The filter can be
cleaned by shaking it or washing it in water.
If you wash the filter, you must let it dry completely before
refitting it.
Take the cleaned/new filter and place it in the bottom of the
container. Press the outer edge of the filter down against
the sides of the container so that the filter bulges up slightly.
Then push the filter down into place. Make sure the filter is
packed in tightly against the motor housing, Fig. 13. Reinstall
the dust bag and replace the lid. Check that the lid is firmly
secured.
4.1 Replacing the dust bag
The central vacuum cleaner is fitted with a dust bag as
standard.
Grasp the edge of the lid and pull upwards to open it, Fig. 10.
Replacing the dust bag: Remove the old dust bag by
turning the cardboard stiffener to the right or left so that the
raised part of the inlet is in line with the opening in the card.
Now slide the bag off the bag nozzle.
Fit the new dust bag as follows: Push the opening in the
cardboard over the elevation on the inlet and pull on the new
bag. Turn the cardboard to lock the bag in place.
The cardboard stiffener locks the bag in place when you
twist it as shown in Fig. 11.
The opening in the card must line up and slide over the
elevation on the inlet before you twist the cardboard
stiffener to lock it.
