14
NORDIC S3
7. Undothescrewinthecentreofthesteelprole.
Releasethetopofthesealingstripsothattheprole
can be removed.
8. Flipothebrushstripproleswithascrewdriver,
etc. There are 4 brush strips on the rotor, 2 on each
side. Use a broad screwdriver, so you can get a good
contactwithoutbendingtheprole.Startatoneend
and continue to the other. Lift it carefully, bit by bit.
9. Pull the brush strips out of the groove.
10. Move the brush strips down to level 2, or replace
them with new ones if they are completely worn out.
11. Pressthebrushstripprolebackintoplace.
8
109
LEVEL 1
LEVEL 2
7
11
