NORDIC S4
grease solvent on a cloth (e.g. methylated spirits) and
compressed air if possible.
NB: Take care that the motor is not exposed to water.
To take out the fans:
1. Unplug.
2. Remove the cover, if there is one, on the fan
compartment.
3. Undo the screws on the electric cover and take the
FRYHUR΍
4. Disconnect the electric quick-release contact by
pressing in at the same time as pulling the contact
apart.
5. Pull the cable bushings for the fans out of the grooves
so that the cables with quick-release contacts come too.
6. Remove the fans by pulling on the holes.
4. Cleaning and maintenance
!
%HIRUHRSHQLQJWKHGRRU6ZLWFKR΍
the heat, let the fans continue for
bPLQXWHVWRUHPRYHKRWDLUXQSOXJ
the unit and wait 2 minutes before
opening the doors.
4.1. CLEANING THE FANS
The fans must be inspected at least once a year
and cleaned as needed. Clean the fan blades with a
21
3
6
x2
4
5
