Flexit Nordic S4 - Door Removal Procedure

9
NORDIC S4
3.1. IF A DOOR NEEDS TO BE REMOVED
7KHGRRUFDQEHOLIWHGR΍ZKHQLWLVRSHQEHWZHHQ
|bDQG|VHH)LJ
If there is limited space in front of the unit, the lock
screw on the underside of the unit can be unscrewed
(see Fig. 2) and the door pushed out sideways (see Fig. 3).
In this case it can be open less than 40º.
!
The door weighs 6.5kg – take care
when removing it.
40-105°
Fig. 1
Fig. 2 Fig. 3
