Replace the Top and Side Covers
a. Install the top cover. The top cover has the vent holes facing backwards towards the rear of the FLEX-5000.
Gently press them on and screw them down.
b. Install the side panels by gently pressing them into place.
Return the FLEX-5000 to the Operating Position
a. Return the FLEX-5000 to its operating position
b. Install the power connector and all other connecting cables.
Install the latest version of PowerSDR
a. Download PowerSDR (v2.0.22 minimum) from the FlexRadio Systems web site (www.flexradio.com)
b. Run the PowerSDR Integrated Installer to ensure that the latest Firewire drivers and firmware are installed to
your PC
Install latest Firmware and Register the ATU with the FLEX-5000 EEPROM
a. Start PowerSDR.
b. If a firmware update is needed, PowerSDR will install it automatically.
c. Once PowerSDR is running, use keyboard sequence CTRL+SHIFT+D to start the FLEX-5000 Debug form.
d. Now execute keyboard sequence CTRL+ALT+A from the FLEX-5000 Debug form to access the ATU Upgrade
button displayed in the center left of the Debug form.
e. Left click on the Update EEPROM button. This will write the ATU serial number and assembly number
information to the FLEX-5000’s EEPROM and registers the ATU.
f. Close the ATU Upgrade form
g. Close the FLEX-5000 Debug form
h. Close PowerSDR
