Getting Started
Required Tools
A number 2 (#2) Phillips Screwdriver
A small flat blade screwdriver
#8 TORX wrench
Materials needed for Service Procedure
One (1) SmartSDR MicroSD Card
One (1) piece of Kapton tape
Two (2) adhesive Warranty Void stickers
Preparing to Install the MicroSD Card
Removing the Chassis Feet
Remove the four (4) feet from the chassis using a #2 Phillips screwdriver as shown in the image below.
Retain the chassis feet and screws for re-installation later.
