Flextherm FLP35 - Page 4

4
© 2016 OJ Electronics A/S
3
2
120 / 240 VAC
L2(N)L1(L)
LINE
1800W / 3600W MAX 15A
LOAD
14
BR1015A01b
© OJ Electronics A/S
Fig. 2
1
234
LOAD
1800W/3600W MAX 15A
LINE
120 / 240 VAC
L1(L)
L2(N)
WARNING
When fastening the screws
do NOT exceed a torque
greater than
1.2 Nm
WARNING
When loosening the screws
do NOT detach the screws
from the terminal.
ES: Advertencia
Al apretar los tornillos no
aplique un par de apriete
mayor que 1,2 N-m.
FR: Avertissement
Lors du serrage des
vis, ne pas excéder un
couple de 1,2 Nm.
ES: Advertencia
Al aflojar los tornillos, no
los separe completamente
del terminal.
FR: Avertissement
En desserrant les vis,
ne pas les enlever
des bornes.
BR928A04
1,6m
Fig. 4
Fig. 3
Fig. 1
BR1015A04a
BR1012D01
© 2016 OJ Electronic A/S
BR1012D02
© 2016 OJ Electronic A/S
BR1012D01, BR1012D020 & BR1015A05
