Flight Display Systems FD104CV User Manual

Document Number:
MAN – FD104CV
Rev:
E
Revision Date:
01/27/2011
Page 5 of 16
Specifications
Display Type
10.4” TFT Color LCD
Display Color
262,144 Colors
Screen Resolution
1024x768 (1280x768 supported)
Brightness
700 cd/m
2
Display Dimensions
8.24”(W) x 6.2” (H)
Weight
3 lbs 8 oz
Power
28V DC @ 1.0A
Video Inputs Supported
S-Video, Composite Video
Video Types Supported
NTSC/PAL
Screen Control
On Screen Display Menu
Mount Materials
Aluminum
DO-160 Testing
Section 21, Category B
Remote Control
IR, included
Installation Instructions
All cabin entertainment equipment, such as the FD104CV, should be installed on a non-
essential bus and have a dedicated circuit breaker. It is a requirement that a switch be
installed in the cockpit so that the pilot can de-energize the entertainment system should it
become necessary.
Rear Connector Orientation – The rear connector of this monitor can be mounted
horizontally (connector perpendicular to rear of monitor) or vertically (connector
perpendicular to bottom of monitor) in order to give you the most convenient mounting
options. By default, this monitor's connector ships in the rear/horizontal position. Flight
Display Systems will ship the unit with the optional bottom/vertical mounting connector
configuration if specified at the time of order; contact your local sales representative for
assistance. It is possible to change the connector orientation at the time of installation.
For instructions on how to change the connector orientation please call Flight Display
Systems at +1 (678) 867-6717 and ask for Technical Support.
