SPECIFICATIONS
Size: ....................................................................................................................... 2.375"W x 1"H x 2.625"D
Weight: ..........................................................................................................................................3.6 ounces
Output......................................................................................................... 375 milliwatts into each 150 ohm
..........................................................................................................headset. Sound level remains constant
............................................................................................................... regardless of the number or type of
...................................................................................................................................... headsets connected.
Power Requirements: ..................................................................................................0.16 amps, 12-28VDC
Warranty ........................................................................................................................ 1 Year Parts & Labor
PARTS LIST
1 .................................................................................................................. 25-pin D-sub connector housing
1 ..................................................................................................................................................... Faceplate
2 ........................................................................................................................................................... Knobs
4 ......................................................................................................................................4-40 Screws (black)
1 .....................................................................................................................25-pin D-sub connector (male)
1 ........................................................................................................................................... 403mc Intercom
1 ......................................................................................................................................................... Manual
4 ....................................................................................................................................... Headphone Jacks*
4 .................................................................................................................................................... Mic Jacks*
8 ............................................................................................................................................................ Nuts*
8 ...................................................................................................................................................... Washers*
4 ............................................................................................................................................ Black Washers*
4 .................................................................................................................... White Nylon or Fiber Washers*
*When purchased with all possible optional jacks
WIRE CONNECTION GUIDE
The following connector pin numbers correspond to the numbers located on the D-sub connector provided with your intercom:
CONNECTOR PIN INTERCOM FUNCTION AIRCRAFT CONNECTION
Pin #1 ..................................................... Ground ..................................................... Avionics ground point
Pin #2 ..................................................... Mic Audio.................................................. Pilot mic
Pin #3 ..................................................... Mic Audio.................................................. Copilot mic
Pin #4 ..................................................... Mic Audio.................................................. Passenger mic
Pin #6 ..................................................... Copilot ...................................................... Copilot PTT Switch
Pin #7 ..................................................... Pilot key .................................................... Pilot PTT Switch
Pin #8 ..................................................... Transmit key ............................................. Comm radio keyline
Pin #9 ..................................................... ICS Audio ................................................. Pilot headphone
Pin #11 ...................................................ICS Audio ................................................. Passenger headphones
Pin #13 ...................................................Mic return ................................................. All mic jacks
Pin #14 ...................................................Mic Audio.................................................. Passenger mic
Pin #16 ...................................................Copilot Transmit Audio .............................. Comm radio
Pin #17 ...................................................Pilot Transmit Audio .................................. Comm radio
Pin #18 ...................................................Aux input................................................... Music system
Pin #20 ...................................................Power in .................................................... 12-28 V, 1 amp breaker
Pin #21 ...................................................Receive Audio .......................................... NavCom/Audio Panel
Pin #23 ...................................................Intercom Mute .......................................... None
Pin #24 ...................................................Aux Mute .................................................. None
Pin #25 ...................................................Mute Activate............................................ None
