70mm
2,76in
70mm
2,76in
33,3mm
1,31in
35mm
1,38in
33,3mm
(2x)
1,31in
2,9mm
0,11in
32,7mm
(3x)
1,29in
182mm
7,16in
172mm
6,76in
12mm
(3x)
0,47in
24mm
(3x)
0,94in
35mm
1,38in
M4 (6x)
UNC 1/4-20 (3x)
Camera with built-in IR lens f=18 mm (25°)
1 2 3 4 5 6 7 8 9 10
1 632 54
A
B
C
D
E
F
G
H
F
C
E
G
D
A
B
-
-
Scale
1:1
A
Size
Modified
R&D Thermography
2012-04-18
CAHA
Basic dimensions FLIR A3xx/SC3xx
T125002
1(8)
A3
Denomination
Drawn by
Check
Size
Drawing No.
Sheet
7
© 2012, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply.
Product may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Diversion contrary to US law is prohibited.
