FLIR A3 series User Manual

172mm
6,76in
280mm
11,03in
101,1mm
3,98in
109mm
4,29in
48mm (2x)
1,89in
33,3mm (2x)
1,31in
96mm
3,78in
Lens support Optional
Base support Optional
108,5mm
4,27in
48mm
1,89in
8mm
0,31in
70mm
2,76in
54,3mm
2,14in
35mm
1,38in
45mm
±0,1
1,77in
±0,00
54,3mm
2,14in
88,5mm
3,48in
54,5mm
2,15in
90mm
±0,1
3,54in
±0,00
UNC 1/4"-20 (5x)
4,17in
105,8mm
For additional dimensions see page 1
Camera with Lens IR f=76 mm (6°) incl support
1 2 3 4 5 6 7 8 9 10
1 632 54
A B
C
D
E
F
G
H
F
C
E
G
D
A B
-
-
Scale
1:1
A
Size
Modified
R&D Thermography
2012-04-18
CAHA
Basic dimensions FLIR A3xx/SC3xx
T125002
5(8)
A3
Denomination
Drawn by
Check
Size
Drawing No.
Sheet
7
