Digital I/O functionality

13.1 FLIR A615 and A655sc

• The state (high or low voltage) on an input pin is used to mark images for use by an

application.

• The state (high or low voltage) on an output pin is controlled by an application.

See the section Technical data for details on voltages, etc.
