412355A-EU V3.1 4/08
3
Operation
POWER BUTTON and AUTO POWER OFF FEATURE
1. Use the POWER button to turn the unit ON or OFF. When the unit is powered up, a
short self-test will ensue after which the display will stabilize.
2. This meter can either be powered by one 9V battery or an AC adapter.
3. When the battery symbol appears on the LCD display, replace the battery as soon as
possible. Low battery power may cause inaccurate readings and erratic meter
operation.
4. This instrument is equipped with Auto Power OFF which turns the meter off after 10
minutes of inactivity. To override this feature; press and hold the MODE button until the
display shows
(auto power off de-activated) or (auto power off
activated).
FUNCTION SLIDE SWITCH
Slide the Function switch on the side of the meter to the desired function (Voltage or
Current)
MODE
Press the MODE button to select either SOURCE (output) or MEASURE (input)
UNIT BUTTON
Press the UNIT button to select:
1. Voltage mode: mV or V in source.
2. Current mode: mA or % in source or measure
▲▼ OUTPUT ADJUST BUTTONS
Press the
▲ ▼buttons to increase or decrease the output voltage or current value in the
source mode.
1. Press the
▲ button once to increase the value in one digit steps.
2. Press and hold the
▲ button to increase the value in 10 digit steps.
3. Press and hold the
▲ button > 2 sec and then press the ▼ to increase the value
in 100 digit steps
4. To decrease the value, use the
▼ button as described above.
ZERO BUTTON
The ZERO button manually zeros the display in the MEASURE mode.
1. Set the meter to the MEASURE mode
2. Short the input jack
3. Press and release the ZERO button.
