910-0001-00-MAN-R06 FLIR Proprietary Information Page 11 of 81
Information contained in this document pertains to a Canadian origin product that is controlled as "dual use" by the Canadian
government. However, when in the United States or possessed by a US person, it may be considered a defense article from the US Government's
perspective. US government authorization may be required for re-transfer to a foreign person. If you have any questions, please contact FLIR's
Global Trade Compliance group at exportquestions@flir.com .
1 INTRODUCTION
This manual describes the Perimeter Surveillance Radar (PSR) system operation. The Operator Manual is
intended for an audience of technically qualified personnel. For installation and configuration of the radar
system, or for more advanced functions, please refer to the installation manual of your specific radar.
Note
Please note that the generic product name “radar” is used throughout this manual for ease of
reading. The given information is valid for products Ranger R1, R2, R3, R3D, R5, R5D, R4SS-X, R6SS-X,
R8SS-X and R20SS unless noted otherwise. Also, the -X in R4SS-X, R6SS-X and R8SS-X refers to the 3
possible variants of each radar, for example R6SS-X can refer to R6SS, R6SS-U or R6SS-3D.
1.1 SAFETY ISSUES
This equipment generates Radio Frequency energy and is intended for outdoor installations only. Based
on limits specified by the Federal Communication Commission (FCC) on Radio Frequency (RF) Emissions,
findings from tests conducted conclude that the R1, R2, R3, R3D, R5, R5D, R4SS-X, R6SS-X, R8SS-X and
R20SS do not represent any safety hazards and are therefore safe for human exposure, provided the
following conditions are met:
Caution!
The installation must provide a separation distance from all persons and must not be co-located or operated in
conjunction with any other antennas or transmitters. This safety distance complies with the FCC Limits for
Maximum Permissible Exposure (MPE) for general population / uncontrolled exposure.
Safety Distances
Output
Power
Frequency
Band
FCC MPE distance (cm)
Controlled Exposure General Population
R20SS (921-0041-00-R0X) 25 Watts X 170 400
R20SS (921-0041-22-R0X)
R20SS (921-0041-23-R0X)
25 Watts X 170 400
R20SS (921-0041-30-R0X) 8 Watts X 90 200
R4SS, R6SS, R8SS
(921-0071-XX-R0X)
2/8/25
Watts
X 50 / 90 / 170 100 / 200 / 400
R4SS-U/3D, R6SS-U/3D,
R8SS-U/3D
(921-0071-XX-R0X)
2/8/25
Watts
X 25 / 40 / 80 45 / 80 / 180
R1,R2,R3, R3D
(921-0011-06-R0X)
0.8 Watt Ka 22 22
R3D (921-0011-06-R06)
(Doppler)
0.8 Watt Ka 22 22
R5 (921-0031-01-R07) 0.56 Watt Ka 10 20
