Frequency Group : R1, R2, R3 and R3D
# of Radars
FastScan
# of Radars
Doppler 3400 m
# of Radars
Doppler 6500 m
Total # of Radars
Up to 8
(chirp slots 0-7)
0 0 Up to 8
Up to 4
(chirp slots 0, 2, 4, 6)
Up to 3
(chirp slots 1, 2, 3)
0 Up to 7
Up to 1
(chirp slot 0)
0
Up to 1
(chirp slot 0)
Up to 3
0
Up to 4
(chirp slots 0, 1, 2, 3)
Up to 2
(chirp slots 0, 1)
Up to 6
0
Up to 4
(chirp slots 0, 1, 2, 3)
0 Up to 4
0
0
Up to 2
(chirp slots 0, 1)
Up to 2
Table 9 - Number of Radars for Multiple Radar Modes R1, R2, R3 and R3D
Frequency Group: R5 and R5D
# of Radars
FastScan
# of Radars
Doppler 5500m
Freq Band 0
# of Radars
Doppler 5500m
Freq Band 1
# of Radars
Doppler 10500m
Freq Band 0
# of Radars
Doppler 10500m
Freq Band 1
Total #
Radars
Up to 8
(chirp slots 0-7)
0 0 0 0 Up to 8
Up to 4
(chirp slots 0, 2,
4, 6)
Up to 2
(slots 0, 1)
Up to 2
(slots 0, 2)
Up to 1
(slot 1)
Up to 1
(slot 0)
Up to 10
0
Up to 3
(slots 0, 1, 2)
Up to 3
(slots 0, 1, 2)
Up to 2
(slots 0, 1)
Up to 2
(slots 0, 1)
Up to 10
Table 10 - Number of Radars for Multiple Radar Modes R5 and R5D
