22 ZH-CN 简体中文
10. 如果已启用自动上传,当热像仪连接至 Internet 时,新图像将自动上传至您
FLIR Ignite 帐户。您也可以手动上传图像。要访问您的 FLIR Ignite
户,请前往 https://ignite.flir.com
您也可以使用 USB 电缆或存储卡从热像仪移出图像。
11. 将图像导入到 FLIR 热成像软件并创建检测报告。
22.9 前视图
请参阅 Figure 1.1 View from the front, 页面 1
1. 自动对焦按钮。
2. 保存按钮。
3. 取景器。
4. 用于更改取景器视觉校正的旋钮。
5. 颈带连接点。
6. 激光接收器。
7. 激光发射器。
8. 热像仪灯(左右两侧)。
9. 红外镜头。
10. 数码相机。
22.10 后视图
请参阅 Figure 1.2 View from the rear, 页面 1
1. 聚焦环。
2. 扬声器。
3. 可编程按钮。
4. 图像存档按钮。
5. 按中央按钮的导航台。
6. 后退按钮。
7. /关按钮。
8. 手带。
9. 多点触控 LCD 屏幕。
10. 灯传感器。
11. 麦克风。
12. 颈带连接点。
22.11 底视图
请参阅 Figure 1.3 View from the bottom, 页面 1
1. 激光开关按钮。
#T810412; r. AE/80342/80342; mul 134
