FLIR TA72 Getting Started

FLIRTA72_TA74‐GETTINGSTARTEDDocumentIdentifier:TA72_TA74‐QS‐mul_AA
TA72_TA74‐GETTINGSTARTED‐EN

USERGUIDELOCATION:ThedetailedUserGuideislocatedintheproductpackagingandonthesupport.flir.comweb
site(downloadtab).PleasereadtheentireUserGuidetogainathoroughunderstandingofthemeterbeforeuse.
RegisterforExtendedWarrantyandProductUpdatesatwww.flir.com/testwarranty
QuickOverview
 Pressandhold topowerONorOFF.
 Themeterispoweredbytwo1.5V‘AAA’batteries(rear
compartment);replacewhenmeterdoesnotpowerON.
 ThemeterwillbeepasitswitchesONandoneofthethreeRange
indicatorswillbelit.Use theRangebuttontochangetherange.
 MeterswitchesOFFautomaticallyafter10minutessofinactivity.
 CurrentMeasurementsarecoveredonthenextpage.
 Forthediagramatright,seethedescriptionsbelow:
1. FlexibleCurrentClampCoil
2. WorkLights
3. Clamplockmechanism
4. Rangeindicators
5. RANGEselectbutton(presstomanuallyrange)
6. PowerandWorkLightsbutton
7. Testleadcableconnection
8. Testleads(connecttoDMMsettoVoltsACrange)
 Whenpowered,press toturnWorkLightsONorOFF.
 PressRANGEforManualRanging(AutoRangeisdefault).
ButtonandIndicatorOverview

Presstostepthroughthera ngesmanually

Withmeteron,presstoactivate/deactivateworklights

PressandholdtoswitchpowerON/OFF

Illuminateswhenthe30Arangeisselected

Illuminateswhenthe300Arangeisselected

Illuminateswhenthe3000Arangeisselected
1
2
3
4
5
6
7

8


