Assembly of Step 4
4-A
4
-
B
NOTE
LIFTING CABLE IN UPWARD
DIRECTION IS PLACED ON POST B
AND POST C.
NOTE
LIFTING CABLE IN DOWNWARD
DIRECTION IS PLACED ON POST A
AND POST D.
